進行大型航空模型制作需繪制什么圖？當然要繪制圖了，比如三維圖，結構圖等，目的是為了更好的制作出效果，大大降低失敗的幾率。下面來看看：

What drawings need to be drawn for the production of large aviation models? Of course, it is necessary to draw diagrams, such as three-dimensional diagrams and structural diagrams, in order to better produce effects and greatly reduce the probability of failure. Let's take a look:

繪制三維圖

Draw a three-dimensional diagram

根據上面的設計和計算結果，我們就可以繪制出自己需要的飛機了。繪制三維圖的主要目的是為了得到您想要的飛機效果，并確定每個部件的形狀和位置。使您在以后的工作中，有一個基本的藍圖。

According to the above design and calculation results, we can draw the plane we need. The main purpose of drawing a three-dimensional diagram is to get the desired aircraft effect and determine the shape and position of each component. So that you have a basic blueprint in your future work.

繪制結構圖

Draw structure diagram

繪制結構圖的主要目的是為了確定每個部件的布局和制作步驟。如：哪個部件用什么材料，先做哪個部件后作哪個部件，部件與部件的結合方法等等。

The main purpose of drawing the structure diagram is to determine the layout and manufacturing steps of each component. For example, which parts are made of what materials, which parts are made first and which parts are made later, and the combination method of parts and components.

航空模型技術常用術語：

Common terms of aviation model technology:

1、翼展——機翼(尾翼)左右翼尖間的直線距離。(穿過機身部分也計算在內)。

1. Wing span - the linear distance between the left and right wingtips of the wing (tail). (The part passing through the fuselage is also included).

2、機身全長——模型飛機很前端到很末端的直線距離。

2. Full length of fuselage - the straight-line distance from the very front to the very end of the model aircraft.

3、——模型飛機各部分重力的合力作用點稱為。

3. Center of gravity - The point of action of the combined force of the gravity of each part of the model aircraft is called the center of gravity.

4、尾心臂——由到水平尾翼前緣四分之一弦長處的距離。

4. Tail center arm - the distance from the center of gravity to the quarter chord length of the leading edge of the horizontal tail.

5、翼型——機翼或尾翼的橫剖面形狀。

5. Airfoil - the cross section shape of a wing or tail.

6、前緣——翼型的很前端。

6. Leading edge - the very front end of the airfoil.

7、后緣——翼型的很后端。

7. Trailing edge - the very rear end of the airfoil.

8、翼弦——前后緣之間的連線。

8. Wing chord - the line between the front and rear edges.

9、展弦比——翼展與平均翼弦長度的比值。展弦比大說明機翼狹長。

9. Aspect ratio - the ratio of wingspan to average chord length. A large aspect ratio indicates that the wing is narrow and long.

放樣和組裝

Setting out and assembly

根據您繪制的圖紙，應做一比一的裝配圖。目的是在組裝飛機各部件時，在裝配圖上粘接各部件。這樣能做到直觀準確，提高工作質量。更多相關內容就來我們網站http://gdzcjy.com咨詢吧！

According to the drawings you draw, you should make a one-to-one assembly drawing. The purpose is to bond all parts on the assembly drawing when assembling all parts of the aircraft. This can be intuitive and accurate, and improve the quality of work. Come to our website for more relevant content http://gdzcjy.com Ask!
